Audio reset
Reset all settings in the Audio menu to factory
preset values.
Audio Out Sync
Enable/disable audio out (line out) volume
adjustability to sync with internal speakers.
6.1.4. Configuration1 menu
Screen
Audio
Configuration 1
Configuration 2
Advanced option
Balance
Treble
Bass
Volume
Audio Out (Line Out)
Maximum Volume
Minimum Volume
Mute
Audio source
Audio reset
Audio Out Sync
50
50
50
30
30
100
0
Off
Digital
Action
Off
Screen
Audio
Configuration 1
Configuration 2
Advanced option
Switch on state
Panel saving
RS232 routing
Boot on source
WOL
Configuration1 reset
Factory reset
Force on
Action
RS232
Action
Off
Action
Action
Switch on state
Select the display status used for the next time
you connect the power cord.
• {Power off} - The display will remain off
when the power cord is connected to a wall
outlet.
• {Forced on} - The display will turn on when
the power cord is connected to a wall outlet.
• {Las
t status} - The display will return to the previous
power status
Panel saving
Choose to enable the panel saving functions and
thus reduce the risk of “image persistence” or
“ghost-imaging”.
• {Brightness} - Select {On} and the image
brightness will be reduced to an appropriate
level.The Brightness setting in the Picture
menu will be unavailable when selected.
• {Pixel shift} - Select the time inter val
({Auto} / {10 ~ 900}
Seconds/
{Off}) for the
display to slightly expand the image size and
shift the position of pixels in four directions
(up, down, left, or right). Activating Pixel
Shift will disable H Position,V Position and
Zoom Mode in the Screen Menu.
Note: Only suppor t external input source
(HDMI,VGA, DP, OPS).
RS232-Routing
Select the network control port.
Choose from: {RS232} / {LAN -> RS232}
Boot on source
Choose to select source when boot up. Input:
select input source when boot up.
Playlist: select playlist index for Media player,
Browser, PDF player.
0: no play list. Same as switch source from
OSD.1~7: playlist number. No failover function,
system will keep source even the source is no
signal input.
WOL
Choose to turn on or off the wake on LAN function.
Choose from : {Off} / { On}
Conguration1reset
Reset all settings in Conguration1 menu to the
factory preset values.
Factory reset
Reset all settings in the OSD menus of
{Picture}, {Screen}, {Audio}, {Conguration1},
{Conguration2}, and {Advanced option} to the
factor y preset values.
Android settings will also reset when factory reset.
Press [
] or [ ] button to select {Reset}, and
press [OK] button to do the reset.
Factory reset
CANCEL Reset
Screen
Audio
Configuration 1
Configuration 2
Advanced option
OSD turn off
OSD H position
OSD V position
Information OSD
Logo
Monitor ID
Heat status
Monitor information
HDMI Version
Configuration2 reset
45
50
50
10
On
Action
24.21°C 75.57°F
Action
Action
Monitor ID
Monitor ID
Monitor group
1
1
1 2
5 6
3
4
7 8
9 10 11 12
13 14 15 16
Monitor information
Model name
Serial NO.
Operation hours
SW Version
CDE5510
N/A
0
FB01.06
6.1.5. Configuration2 menu
Factory reset
CANCEL Reset
Screen
Audio
Configuration 1
Configuration 2
Advanced option
OSD turn off
OSD H position
OSD V position
Information OSD
Logo
Monitor ID
Heat status
Monitor information
HDMI Version
Configuration2 reset
45
50
50
10
On
Action
24.21°C 75.57°F
Action
Action
Monitor ID
Monitor ID
Monitor group
1
1
1 2
5 6
3
4
7 8
9 10 11 12
13 14 15 16
Monitor information
Model name
Serial NO.
Operation hours
SW Version
CDE5510
N/A
0
FB01.06
OSD turn off
Set the period of time the OSD (on-screen
display) menu stays on the screen.
The options are: {Off, 5 ~ 120} seconds.
*{0ff} does not disappear automatically.
