52
Get-PIP mode 8 g t 74
000: OFF
001: PIP (POP)
002: PBP
Get-PIP input 8 g u 75 000 ~ See Set-input select
Get-Tiling Mode 8 g v 76
000: OFF
001: ON
(for Video wall)
Get-Tiling
Compensation
8 g w 77
000: OFF
001: ON
(for Video wall)
Bezel width compensation
Get-Tiling H by V
monitors
8 g x 78
01x~09x: H monitors
0x1~0x9: V monitors
(for Video wall)
1. 2
nd
digital for H monitors
2. 3
rd
digital for V monitors
Get-Tiling
position
8 g y 79
000: OFF
001~025
(for Video wall)
Copy the screen of
Position# to identified
display
Get-Date: Year 8 g 2 32 Y00~Y00
Last 2 digits
(20)17~(20)99
Get-Date: Month 8 g 2 32 M00~M00 2 digits
Get-Date: Day 8 g 2 32 D00~M00 2 digits
Get-Time: Hour 8 g 3 33 H00~H00 24-hr format. 2 digits
Get-Time: Min 8 g 3 33 M00~M00 2 digits
Get-Time: Sec 8 g 3 33 S00~S00 2 digits
Get-RS232
version
8 g 6 36 001~ Version 0.0.1~9.9.9
11.3.3. Remote Control Pass-through mode
When the PC sets the TV/DS to Remote Control Pass through mode, the TV/DS will send a 7-byte packet
(followed by “CR”) in response to RCU button activation. Note, that in this mode the RCU shall have no
effect on the TV/DS function. For example: “Volume+” will not change the volume in the LCD but only sends
“Volume+” code to PC over the RS232 port.
IR Pass Through-Function format
Reply: (Command Type=”p”)
Name Length ID
Command
Type
RCU Code1
(MSB)
RCU Code2
(LSB)
CR
Byte Count 1 Byte 2 Byte 1 Byte 1 Byte 1 Byte 1 Byte
Bytes order 1 2~3 4 5 6 7
Example1: Remote Control pass-through when “VOL+” key is pressed for TV-05 Send (Hex Format)
Name Length ID
Command
Type
Command Value1 CR
Hex
0x36
0x30
0x35
0x70 0x31 0x30 0x0D
