Key Code (HEX)
1 01
2 02
3 03
4 04
5 05
6 06
7 07
8 08
9 09
0 0A
- 0B
RECALL (LAST) 0C
INFO (DISPLAY) 0D
0E
ASPECT (ZOOM, SIZE) 0F
VOLUME UP (+) 10
VOLUME DOWN (-) 11
MUTE 12
CHANNEL/PAGE UP (+)/
BRIGHTNESS+
13
CHANNEL/PAGE DOWN (-)/
BRIGHTNESS-
14
POWER 15
SOURCES (INPUTS) 16
17
18
SLEEP 19
MENU 1A
UP 1B
DOWN 1C
LEFT (-) 1D
RIGHT (+) 1E
OK (ENTER, SET) 1F
EXIT 20
21
22
23
24
25
26
27
28
29
2A
2B
RED ■ (F1) 2C
GREEN ■ (F2) 2D
YELLOW ■ (F3) 2E
BLUE ■ (F4) 2F
NOTE:
1. This IR-pass-through code is dierent from the
RCU key code.
2. Special control sequence for POWER key
under IR-pass through mode.
2-1. When TV/DS is OFF and receives the IR
POWER code: TV/DS will turn itself on,
then forward the POWER code to the
host via RS232.
2-2. When TV/DS is ON and receives the IR
POWER code: TV/DS will forward the
POWER code to the host via RS232,
then turn o itself.
2-3. When SET-POWER LOCK is enabled,
the TV/DS will not respond to POWER key pressing.
3. The VOLUME UP and VOLUME DOWN code
will repeatedly output when you press and hold the
keys.
