96
VOLUME DOWN (-) 11 V
MUTE 12 V
CHANNEL/PAGE UP (+)/
BRIGHTNESS+
13 V
CHANNEL/PAGE DOWN (-)/
BRIGHTNESS-
14 V
POWER 15 V
SOURCES (INPUTS) 16 V
17
18
SLEEP 19 V
MENU 1A V
UP 1B V
DOWN 1C V
LEFT (-) 1D V
RIGHT (+) 1E V
OK (ENTER, SET) 1F V
EXIT 20 V
21
22
23
24
25
26
27
28
29
2A
2B
RED ■ (F1) 2C
GREEN ■ (F2) 2D
1. This IR-pass-through code is dierent from the RCU key code.
2. Special control sequence for POWER key under IR-pass through mode.
2-1. When Display is OFF and receives the IR POWER code: Display will turn itself
on, then forward the POWER code to the host via RS-232.
2-2. When Display is ON and receives the IR POWER code: Display will forward the
POWER code to the host via RS-232, then turn o itself.
