ViewSonic IFP6552-2F - Connecting External Devices and Touch Connection

167 pages

To Next Page

To Previous Page

Connecng External Devices and Touch Connecon

Computer

TOUCH

VGA

USB Cable

TOUCH

USB Cable

DP Cable

USB Cable

VGA Cable

HDMI Cable

HDMI

TOUCH

Type C Cable

Type-C
