Control Panel
LED
1. POWER (Power LED indicator)
2. LAMP (Lamp LED indicator)
Button
1.
2. MENU\ENTER
3. KEYSTONE (

/

)
4. AUTO (

)
5. Four direction buttons
6. SOURCE (

)
Interface Connector
1. Service connector
This connector is used for engineering purpose.
2. AUDIO input connector
Connect an audio output from video equipment to this jack.
3. COMPUTER IN (D-SUB) connector
Connect image input signal (analog) to this connector.
4. S-VIDEO connector
Connect S-Video output from video equipment to this jack.
5. VIDEO connector
Connect composite video output from video equipment to this jack.
1
2
3
6
5
1
2
4
1
2
3
4
5
SERVICE
