ViewSonic PJD5133 User Manual

Connecting a computer or monitor
Connecting a computer
The projector provides two VGA input sockets that allow you to connect them to both!
IBM
®
compatibles and Macintosh
®
computers. A Mac adapter is needed if you are!
connecting legacy version Macintosh computers.
To connect the projector to a notebook or desktop computer:
1. Take the supplied VGA cable and connect one end to the D-Sub output socket of
the computer.
2. Connect the other end of the VGA cable to the COMPUTER IN 1 or COMPUTER
IN 2 signal input socket on the projector.
Important
 Many notebooks do not turn on their external video ports when connected to
a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the
external display on/off. Locate a function key labeled CRT/LCD or a function
key with a monitor symbol on the notebook. Press FN and the labeled
function key simultaneously. Refer to your notebook's documentation to find
your notebook's key combination.
Connecting a monitor
If you want to view your presentation close-up on a monitor as well as on the screen,
you can connect the COMPUTER OUT signal output socket on the projector to an
external monitor with a VGA cable following the instructions below:
To connect the projector to a monitor:
1. Connect the projector to a computer as described in “Connecting a computer” on
page 16.
2. Take a suitable VGA cable (only one supplied) and connect one end of the cable
to the!D-Sub input socket of the video monitor.
Or if your monitor is equipped with a DVI input socket, take a VGA to DVI-A cable
and connect the DVI end of the cable to the DVI input socket of the video monitor.
3. Connect the other end of the cable to the COMPUTER OUT socket on the
projector.
Important
 The COMPUTER OUT output only works when COMPUTER IN 1 or
COMPUTER IN 2 is made to the projector.
16

ViewSonic PJD5133 Specifications

General

Matrix size	0.55 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Projection technology	DLP
Supported aspect ratios	4:3, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	27 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Power LED	Yes
Audio input	1
Aspect ratio	16:10
Compatibility	PC, Mac
Dimensions (WxDxH)	284 x 234 x 82 mm
Connectivity technology	Wired
Focus	Manual
Optical zoom	1.1 x
Focal length range	- mm
Lamp power	180 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
DVI port	No
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC 3.58, NTSC 4.43, NTSC M, PAL, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K1, SECAM L
Supported graphics resolutions	800 x 600 (SVGA)
RMS rated power	2 W
Product type	Standard throw projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	235 W
Noise level	32 dB
Certification	CB, CCC, PSB, C-tick, KC, SASO, CE, GOST-R, Ukr, ErP, SVHC list & REACH DoC, UL, FCC (including ICES-003), cUL/CSA, Argen, NOM
Noise level (economic mode)	30 dB
Storage temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, VGA
Sustainability certificates	RoHS

Weight and Dimensions

Depth	234 mm
Width	284 mm
Height	82 mm
Weight	2600 g
Package weight	3400 g
