ViewSonic PJD5133 User Manual

RS-232 Command and Configuration
Function Action Control Code Return
Code
Power Power on BE,EF,10,05,00,C6,FF,11,11,01,00,01,00 6
Power off BE,EF,03,06,00,DC,DB,69,00,00,00,00,00 6
Source input Computer1 BE,EF,03,19,00,19,29,01,47,02,CC,CC,00 6
Computer2 BE,EF,03,19,1E,90,72,01,47,02,CC,CC,00 6
S-Video BE,EF,03,19,00,E8,69,01,47,02,CC,CC,00 6
Video BE,EF,03,19,00,78,A8,01,47,02,CC,CC,00 6
HDMI BE,EF,03,19,00,DA,2B,01,47,02,CC,CC,00 6
Projector
position
Front table BE,EF,10,07,9F,9D,0E,0A,EF,00,00,00,00 6
Rear table BE,EF,10,07,9F,9D,0E,0A,EF,01,00,00,01 6
Front ceiling BE,EF,10,07,9F,9D,0E,0A,EF,02,00,00,02 6
Rear ceiling BE,EF,10,07,9F,9D,0E,0A,EF,03,00,00,03 6
OSD Menu BE,EF,02,06,00,E9,D3,30,00,00,00,00,00 6
Up BE,EF,02,06,00,6D,D2,34,00,00,00,00,00 6
Down BE,EF,02,06,00,0B,D2,32,00,00,00,00,00 6
Left BE,EF,02,06,00,DA,D3,33,00,00,00,00,00 6
Right BE,EF,02,06,00,38,D2,31,00,00,00,00,00 6
Lamp ECO on BE,EF,03,06,00,EF,DB,6A,00,00,00,00,00 6
ECO off BE,EF,03,06,00,3E,DA,6B,00,00,00,00,00 6
Using hours BE,EF,03,06,00,BA,DB,6F,00,00,00,00,00 xxxx
Fan High Attitude on BE,EF,02,06,00,40,D3,80,00,00,00,00,01 6
High Attitude off BE,EF,02,06,00,40,D3,80,00,00,00,00,00 6
Keystone Keystone up BE,EF,03,06,00,10,DB,65,00,00,00,00,00 6
Keystone down BE,EF,03,06,00,23,DB,66,00,00,00,00,00 6
Aspect ratio 4:3 BE,EF,03,06,00,0D,DA,68,00,01,00,00,01 6
16:9 BE,EF,03,06,00,0D,DA,68,00,02,00,00,02 6
16:10 BE,EF,03,06,00,0D,DA,68,00,03,00,00,03 6
Blank Blank on BE,EF,02,06,00,DF,DF,66,00,01,00,00,01 6
Blank off BE,EF,02,06,00,DF,DF,66,00,02,00,00,02 6
Freeze Freeze on BE,EF,02,06,00,02,D0,2B,00,01,00,00,01 6
Freeze off BE,EF,02,06,00,02,D0,2B,00,02,00,00,02 6
Volume Volume + BE,EF,02,06,00,F1,DE,68,00,00,00,00,00 6
Volume - BE,EF,02,06,00,20,DF,69,00,00,00,00,00 6
Mute on BE,EF,02,06,00,0E,DE,67,00,01,00,00,01 6
Mute off BE,EF,02,06,00,0E,DE,67,00,02,00,00,02 6
Auto source Auto source on BE,EF,03,06,00,89,DB,6C,00,00,00,00,00 6
Auto source off BE,EF,03,06,00,58,DA,6D,00,00,00,00,00 6
Auto Sync BE,EF,02,06,00,86,D1,2F,00,00,00,00,00 6
42

ViewSonic PJD5133 Specifications

General

Matrix size	0.55 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Projection technology	DLP
Supported aspect ratios	4:3, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	27 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Power LED	Yes
Audio input	1
Aspect ratio	16:10
Compatibility	PC, Mac
Dimensions (WxDxH)	284 x 234 x 82 mm
Connectivity technology	Wired
Focus	Manual
Optical zoom	1.1 x
Focal length range	- mm
Lamp power	180 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
DVI port	No
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC 3.58, NTSC 4.43, NTSC M, PAL, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K1, SECAM L
Supported graphics resolutions	800 x 600 (SVGA)
RMS rated power	2 W
Product type	Standard throw projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	235 W
Noise level	32 dB
Certification	CB, CCC, PSB, C-tick, KC, SASO, CE, GOST-R, Ukr, ErP, SVHC list & REACH DoC, UL, FCC (including ICES-003), cUL/CSA, Argen, NOM
Noise level (economic mode)	30 dB
Storage temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, VGA
Sustainability certificates	RoHS
