ViewSonic PJD5133 User Manual

details.
Connecting a composite Video source device
Examine your Video source device to determine if it has a set of unused composite
Video output sockets available:
 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to the
device.
To connect the projector to a composite Video source device:
1. Take a Video cable and connect one end to the composite Video output socket of
the ! Video source device.
2. Connect the other end of the Video cable to the VIDEO socket on the projector.
Important
 If the selected video image is not displayed after the projector is turned on
and the correct video source has been selected, check that the Video source
device is turned on and operating correctly. Also check that the signal cables
have been connected correctly.
 You need only connect to this device using a composite Video connection if
Component Video and S-Video inputs are unavailable for use. See
“Connecting Video source devices” on page 17 for details.
19

ViewSonic PJD5133 Specifications

General

Matrix size	0.55 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Projection technology	DLP
Supported aspect ratios	4:3, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	27 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Power LED	Yes
Audio input	1
Aspect ratio	16:10
Compatibility	PC, Mac
Dimensions (WxDxH)	284 x 234 x 82 mm
Connectivity technology	Wired
Focus	Manual
Optical zoom	1.1 x
Focal length range	- mm
Lamp power	180 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
DVI port	No
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC 3.58, NTSC 4.43, NTSC M, PAL, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K1, SECAM L
Supported graphics resolutions	800 x 600 (SVGA)
RMS rated power	2 W
Product type	Standard throw projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	235 W
Noise level	32 dB
Certification	CB, CCC, PSB, C-tick, KC, SASO, CE, GOST-R, Ukr, ErP, SVHC list & REACH DoC, UL, FCC (including ICES-003), cUL/CSA, Argen, NOM
Noise level (economic mode)	30 dB
Storage temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, VGA
Sustainability certificates	RoHS

Weight and Dimensions

Depth	234 mm
Width	284 mm
Height	82 mm
Weight	2600 g
Package weight	3400 g
