Network Connection

IPC

Network Cable Network Cable

Switch

Router

Computer

● Access Through IP-Tool

① Make sure that the camera and the PC are connected to the local

network.

② Install IP-Tool from the CD and run it after installation.

Device Network Search

Immediate Re fresh

name

IPC

unknown

192.168. 226 .201

192.168. 1.2

192.168. 1.3

9008

255.255.

Modify Net wor k Parameter

Mac Addr ess

IP Addr ess

Modify

CE :98 :23 :75 : 35 :2 2

192 . 16 8 . 226 . 2 01

255 . 255 . 255 . 0

192 . 16 8 . 226 . 1

Tip: Enter the adminis tra tor password, and

then modif y the n etwork parameters.

Total Device : 3

Local IP Address:192.1 68. 1.4

Subne t Mas k:2 55.255. 255 . 0 Gateway: 1 92. 168. 1.1 DNS：210. 21 . 196. 6

Device Nam e Dev ice Type IP Addr ess Http Port Data Port

Subnet

Product Mo del

About

Subne t Mas k

Gateway

Restore IPC Default Configuration

⑤ Install the dome and enclosure to the mounting base.

(a). Loosen the nut from the main element.

b . Run the network cable (without RJ 45 connector) through the

both elements. Then crimp the cable with RJ 45 connector.

c . Connect the cable to the hermetic connector. Then tighten the

nut and the main cover.

( )

(a)

(b)

( )

④ Secure the mounting base to the ceiling or wall with the screws provided.

Then adjust the dome to obtain an optimum view angle.

0 ~75° °

0 ~360° °

⑥ Finally, fix the camera with the fixed screw.

Fixed screw

③ Modify the IP address. The default IP address of this camera is

192.168.226.201. Click the information of the camera listed in the

above table to show the network information on the right hand.

Modify the IP address and gateway of the camera and make sure its

network address is in the same local network segment as the

computer’s. Please modify the IP address of your device according

to the practical situation.

Mac Address

IP Address

Modify Network Parameter

Modify

CE :98 :23 :75 :35 :22

192 .168 . 1 . 201

255 . 255 . 255 . 0

192 .168 . 1 . 1

Subnet Mask

Gateway

For example, the IP address of your computer is 192.168.1.4. So the

IP address of the camera shall be changed to 192.168.1.X. After

modification, please enter the password of the administrator and click

“Modify” button to modify the setting.

The default password of the administrator is “123456”.

④ Double-click the camera listed in the IP-Tool or manually enter

the IP address in the address bar of the web browser to connect IP

camera. Then follow directions to download and install the plugin.

⑤ Enter the username and password in the login interface.

The default username is admin; the default password is 123456.

450043001853 A0

Telecamera Dome IP a colori Day & Night, sensore CMOS 1/2,8", risoluzione

2 Mpx (1920x1080), obiettivo fuoco fisso 3,6 mm, filtro IR meccanico, H.265 e

H.264 Multistream, funzioni AV, alimentazione PoE o 12 Vdc, IR 20-30 m, funzioni

WDR, 3DNR, HLC, BLC, Mask, Motion, Smart IR, RTSP, protocollo ONVIF, grado

di protezione IP67. Dimensioni: Ø 95x83 mm. Peso 430 g.

Contenuto della confezione

Una volta ricevuto il dispositivo, controllare gli accessori indicati di seguito. Le illu-

strazioni sotto riportate hanno solo funzione di riferimento. Far riferimento all'appa-

recchiatura in dotazione.

Introduzione

Questa telecamera IP (abbreviato in IP-CAM) è stata progettata per fornire soluzioni

TVCC ad elevate prestazioni. Adotta chip di elaborazione video allo stato dell'arte.

Utilizza le tecnologie più avanzate, di codica e decodica video ed è conforme al

protocollo TCP/IP, SoC.(System on chip) ecc. per assicurare la stabilità e l'a󰀩dabilità

del sistema. I manuali completi e i software CVM.exe, Iptool.exe e Diskcalculator.exe

sono disponibili nella scheda prodotto consultabile nel sito www.vimar.com

Connessioni

Di seguito sono riportate le principali connessioni della telecamera.

ENIT

Installazione

Prima di iniziare, assicurarsi che la parete o il so󰀩tto siano su󰀩cientemente solidi

per sopportare tre volte il peso della telecamera. La procedura di montaggio è la

seguente:

1) Allentare la vite di ssaggio per smontare la telecamera.

2) Praticare i fori per le viti e per il cavo sulla parete utilizzando la dima di foratura.

3) Passare i cavi e collegare il cavo di alimentazione e il cavo di rete.

4) Fissare la base di montaggio della telecamera alla parete con le viti, come

descritto di seguito.

5) Prima della regolazione, visualizzare l’immagine della telecamera su un moni-

tor per regolare l’angolo di visuale della telecamera, quindi ssare la ghiera con

la vite di ssaggio.

6) Per completare l'installazione rimuovere delicatamente la pellicola di protezione.

Installation

Before start, please make sure that the wall or ceiling is strong enough to withstand

3 times the weight of the camera. The mounting steps are as follows:

Loosen the xed screw to disassemble the camera.

Drill the screw holes and the cable hole on the wall according to the drill template

3) Route the cables and connect the power cable and video cable.

4) Secure the mounting base with camera to the wall with screws as shown below.

5) Before the adjustment, display the image to a monitor and then adjust the camera

and then loosen the xed ring to adjust the view angle of the camera angle. Final-

ly, x the camera with the xed screw.

6) Remove the protective lm to complete the installation procedure.

Telecamera

Camera

Istruzioni per l’uso

Quick and start guide

Dima di foratura

Drill template

Viti

Screws & spiles

Cacciavite

Screw-driver

Cappuccio impermeabile

Water-proof Cap

Introduction

This IP-camera (short for IP-CAM) is designed for high performance CCTV solu-

tions. It adopts state of the art video processing chips. It utilizes most advanced

technologies, such as video encoding and decoding technology, complies with the

TCP/IP protocol, SoC (System on chip), etc to ensure this system more stable and

reliable. Complete manuals and CVM.exe, Iptool.exe e Diskcalculator.exe software are

available to download in the Product info sheet section of www.vimar.com website.

Connections

Here below the main connections of the camera.

IP Dome Day&Night colour camera, CMOS 1/2.8" sensor, 2 Mpx (1920x1080) res-

olution, 3.6 mm fixed focus lens, mechanic IR filter, H.265 and H.264 Multistream,

VA functions, PoE or 12 Vdc supply, IR 20-30 m, WDR, 3DNR, HLC, BLC, Mask,

Motion, Smart IR, RTSP functions, ONVIF protocol, IP67 protection degree.

Dimensions: Ø 95x83 mm. Weight 430 g.

Package content

After you receive your device, please check the following accessories. The pictures

here are for reference only.

1 Cavo di rete / Network Cable

2 Cavo alimentazione / Power Cable

3 Base di ssaggio / Mounting base

4 Vite di ssaggio / Fixing screw

5 Microfono / Microphone

6 Slot micro SD card / Micro SD card slot

7 Reset

1 2

Installazione della base

Base mounting

Montaggio alla base

Mounting to the base

Ø51,0 mm

Ø4,5 mm

Ø91,6 mm

44,2 mm

38,2 mm

Package

Overview

Installation

Warning and Caution

■ If the product does not work properly, please contact your dealer

or the nearest service center. Never attempt to disassemble the

camera yourself. (We shall not be responsible for any problems

caused by unauthorized repair or maintenance.)

■ Do not allow water or liquid intrusion into the camera.

■ In the use of the product, you must be strict compliance with the

electrical safety regulations of the nation and region. When the

product is mounted on wall or ceiling, the device shall be firmly

fixe

■ Do not use camera beyond specified voltage range.

■ Do not drop the camera or subject it to physical shock.

■ Avoid touching the camera lens.

■ If cleaning is necessary, please use clean cloth to wipe it gently.

■ Do not aim the camera at the sun or extra bright place.

■ Do not place the camera in extremely hot, cold (the operating

temperature shall be -30˚C~60˚C), dusty or damp locations, and do

not expose it to high electromagnetic radiation.

■ To avoid heat accumulation, good vent

ilation is required for

operating environment.

Quick Start Guide

Network Camera

Camera

Quick

start guide

Plastic

plug ×3

Drill template

Screwdriver

Tapping screws × 3

■ Please read this instruction carefully before operating the

unit and keep it for further reference.

■ All the examples and pictures used here are for reference only.

■ The contents of this manual are subject to change without

notice.

* 1 It is recommended to install the security cap for outdoor installation.

* 2 If the PoE switch is used to power the camera, DC12V power supply is not

required.

Security Cap

Ethernet connector

Micro SD card slot

Power connector

Reset

Fixed screw

Mounting base

Fixed Screw

Mounting Base

Enclosure

Dome

DC12V

Microphone

Please make sure that the wall or ceiling is strong enough to

withstand 3 times the weight of the camera. Please install and use

the camera in the dry environment.

① Loosen the fixed screw to disassemble the camera.

② Unscrew the cover of the dome and then insert a micro SD card.

After that, install back the cover and make sure the cover is installed

firmly.

Insert a micro SD card

Cover

③ Drill the screw holes and the cable hole on the ceiling according

to the drill template. Then route and connect the cables.

Earth wire connection

(mm)

Ø4.5

Ø51.0

Ø91.6

44.2

38.2

Package

Overview

Installation

Warning and Caution

■ If the product does not work properly, please contact your dealer

or the nearest service center. Never attempt to disassemble the

camera yourself. (We shall not be responsible for any problems

caused by unauthorized repair or maintenance.)

■ Do not allow water or liquid intrusion into the camera.

■ In the use of the product, you must be strict compliance with the

electrical safety regulations of the nation and region. When the

product is mounted on wall or ceiling, the device shall be firmly

fixe

■ Do not use camera beyond specified voltage range.

■ Do not drop the camera or subject it to physical shock.

■ Avoid touching the camera lens.

■ If cleaning is necessary, please use clean cloth to wipe it gently.

■ Do not aim the camera at the sun or extra bright place.

■ Do not place the camera in extremely hot, cold (the operating

temperature shall be -30˚C~60˚C), dusty or damp locations, and do

not expose it to high electromagnetic radiation.

■ To avoid heat accumulation, good vent

ilation is required for

operating environment.

Quick Start Guide

Network Camera

Camera

Quick

start guide

Plastic

plug ×3

Drill template

Screwdriver

Tapping screws × 3

■ Please read this instruction carefully before operating the

unit and keep it for further reference.

■ All the examples and pictures used here are for reference only.

■ The contents of this manual are subject to change without

notice.

* 1 It is recommended to install the security cap for outdoor installation.

* 2 If the PoE switch is used to power the camera, DC12V power supply is not

required.

Security Cap

Ethernet connector

Micro SD card slot

Power connector

Reset

Fixed screw

Mounting base

Fixed Screw

Mounting Base

Enclosure

Dome

DC12V

Microphone

Please make sure that the wall or ceiling is strong enough to

withstand 3 times the weight of the camera. Please install and use

the camera in the dry environment.

① Loosen the fixed screw to disassemble the camera.

② Unscrew the cover of the dome and then insert a micro SD card.

After that, install back the cover and make sure the cover is installed

firmly.

Insert a micro SD card

Cover

③ Drill the screw holes and the cable hole on the ceiling according

to the drill template. Then route and connect the cables.

Earth wire connection

(mm)

Ø4.5

Ø51.0

Ø91.6

44.2

38.2

Package

Overview

Installation

Warning and Caution

■ If the product does not work properly, please contact your dealer

or the nearest service center. Never attempt to disassemble the

camera yourself. (We shall not be responsible for any problems

caused by unauthorized repair or maintenance.)

■ Do not allow water or liquid intrusion into the camera.

■ In the use of the product, you must be strict compliance with the

electrical safety regulations of the nation and region. When the

product is mounted on wall or ceiling, the device shall be firmly

fixe

■ Do not use camera beyond specified voltage range.

■ Do not drop the camera or subject it to physical shock.

■ Avoid touching the camera lens.

■ If cleaning is necessary, please use clean cloth to wipe it gently.

■ Do not aim the camera at the sun or extra bright place.

■ Do not place the camera in extremely hot, cold (the operating

temperature shall be -30˚C~60˚C), dusty or damp locations, and do

not expose it to high electromagnetic radiation.

■ To avoid heat accumulation, good vent

ilation is required for

operating environment.

Quick Start Guide

Network Camera

Camera

Quick

start guide

Plastic

plug ×3

Drill template

Screwdriver

Tapping screws × 3

■ Please read this instruction carefully before operating the

unit and keep it for further reference.

■ All the examples and pictures used here are for reference only.

■ The contents of this manual are subject to change without

notice.

* 1 It is recommended to install the security cap for outdoor installation.

* 2 If the PoE switch is used to power the camera, DC12V power supply is not

required.

Security Cap

Ethernet connector

Micro SD card slot

Power connector

Reset

Fixed screw

Mounting base

Fixed Screw

Mounting Base

Enclosure

Dome

DC12V

Microphone

Please make sure that the wall or ceiling is strong enough to

withstand 3 times the weight of the camera. Please install and use

the camera in the dry environment.

① Loosen the fixed screw to disassemble the camera.

② Unscrew the cover of the dome and then insert a micro SD card.

After that, install back the cover and make sure the cover is installed

firmly.

Insert a mic ro SD card

Cover

③ Drill the screw holes and the cable hole on the ceiling according

to the drill template. Then route and connect the cables.

Earth wire conne ction

(mm)

Ø4. 5

Ø51 .0

Ø91 .6

44. 2

38. 2

Network Connection

IPC

Network Cable Network Cable

Switch

Router

Computer

● Access Through IP-Tool

① Make sure that the camera and the PC are connected to the local

network.

② Install IP-Tool from the CD and run it after installation.

Device Network Search

Immediate Re fresh

name

IPC

unknown

192.168. 226 .201

192.168. 1.2

192.168. 1.3

9008

255.255.

Modify Net wor k Parameter

Mac Addr ess

IP Addr ess

Modify

CE :98 :23 :75 : 35 :2 2

192 . 16 8 . 226 . 2 01

255 . 255 . 255 . 0

192 . 16 8 . 226 . 1

Tip: Enter the adminis tra tor password, and

then modif y the n etwork parameters.

Total Device : 3

Local IP Address:192.1 68. 1.4

Subne t Mas k:2 55.255. 255 . 0 Gateway: 1 92. 168. 1.1 DNS：210. 21 . 196. 6

Device Nam e Dev ice Type IP Addr ess Http Port Data Port

Subnet

Product Mo del

About

Subne t Mas k

Gateway

Restore IPC Default Configuration

⑤ Install the dome and enclosure to the mounting base.

(a). Loosen the nut from the main element.

b . Run the network cable (without RJ 45 connector) through the

both elements. Then crimp the cable with RJ 45 connector.

c . Connect the cable to the hermetic connector. Then tighten the

nut and the main cover.

( )

(a)

(b)

( )

④ Secure the mounting base to the ceiling or wall with the screws provided.

Then adjust the dome to obtain an optimum view angle.

0 ~75° °

0 ~360° °

⑥ Finally, fix the camera with the fixed screw.

Fixed screw

③ Modify the IP address. The default IP address of this camera is

192.168.226.201. Click the information of the camera listed in the

above table to show the network information on the right hand.

Modify the IP address and gateway of the camera and make sure its

network address is in the same local network segment as the

computer’s. Please modify the IP address of your device according

to the practical situation.

Mac Address

IP Address

Modify Network Parameter

Modify

CE :98 :23 :75 :35 :22

192 .168 . 1 . 201

255 . 255 . 255 . 0

192 .168 . 1 . 1

Subnet Mask

Gateway

For example, the IP address of your computer is 192.168.1.4. So the

IP address of the camera shall be changed to 192.168.1.X. After

modification, please enter the password of the administrator and click

“Modify” button to modify the setting.

The default password of the administrator is “123456”.

④ Double-click the camera listed in the IP-Tool or manually enter

the IP address in the address bar of the web browser to connect IP

camera. Then follow directions to download and install the plugin.

⑤ Enter the username and password in the login interface.

The default username is admin; the default password is 123456.

450043001853 A0

Network Connection

IPC

Network Cable Network Cable

Switch

Router

Computer

● Access Through IP-Tool

① Make sure that the camera and the PC are connected to the local

network.

② Install IP-Tool from the CD and run it after installation.

Device Network Search

Immediate Re fresh

name

IPC

unknown

192.168. 226 .201

192.168. 1.2

192.168. 1.3

9008

255.255.

Modify Net wor k Parameter

Mac Addr ess

IP Addr ess

Modify

CE :98 :23 :75 : 35 :2 2

192 . 16 8 . 226 . 2 01

255 . 255 . 255 . 0

192 . 16 8 . 226 . 1

Tip: Enter the adminis tra tor password, and

then modif y the n etwork parameters.

Total Device : 3

Local IP Address:192.1 68. 1.4

Subne t Mas k:2 55.255. 255 . 0 Gateway: 1 92. 168. 1.1 DNS：210. 21 . 196. 6

Device Nam e Dev ice Type IP Addr ess Http Port Data Port

Subnet

Product Mo del

About

Subne t Mas k

Gateway

Restore IPC Default Configuration

⑤ Install the dome and enclosure to the mounting base.

(a). Loosen the nut from the main element.

b . Run the network cable (without RJ 45 connector) through the

both elements. Then crimp the cable with RJ 45 connector.

c . Connect the cable to the hermetic connector. Then tighten the

nut and the main cover.

( )

(a)

(b)

( )

④ Secure the mounting base to the ceiling or wall with the screws provided.

Then adjust the dome to obtain an optimum view angle.

0 ~75° °

0 ~360

° °

0 ~360° °

⑥ Finally, fix the camera with the fixed screw.

Fixed screw

③ Modify the IP address. The default IP address of this camera is

192.168.226.201. Click the information of the camera listed in the

above table to show the network information on the right hand.

Modify the IP address and gateway of the camera and make sure its

network address is in the same local network segment as the

computer’s. Please modify the IP address of your device according

to the practical situation.

Mac Address

IP Address

Modify Network Parameter

Modify

CE :98 :23 :75 :35 :22

192 .168 . 1 . 201

255 . 255 . 255 . 0

192 .168 . 1 . 1

Subnet Mask

Gateway

For example, the IP address of your computer is 192.168.1.4. So the

IP address of the camera shall be changed to 192.168.1.X. After

modification, please enter the password of the administrator and click

“Modify” button to modify the setting.

The default password of the administrator is “123456”.

④ Double-click the camera listed in the IP-Tool or manually enter

the IP address in the address bar of the web browser to connect IP

camera. Then follow directions to download and install the plugin.

⑤ Enter the username and password in the login interface.

The default username is admin; the default password is 123456.

450043001853 A0

Network Connection

IPC

Network Cable Network Cable

Switch

Router

Computer

● Access Through IP-Tool

① Make sure that the camera and the PC are connected to the local

network.

② Install IP-Tool from the CD and run it after installation.

Device Network Search

Immediate Re fresh

name

IPC

unknown

192.168. 226 .201

192.168. 1.2

192.168. 1.3

9008

255.255.

Modify Net wor k Parameter

Mac Addr ess

IP Addr ess

Modify

CE :98 :23 :75 : 35 :2 2

192 . 16 8 . 226 . 2 01

255 . 255 . 255 . 0

192 . 16 8 . 226 . 1

Tip: Enter the adminis tra tor password, and

then modif y the n etwork parameters.

Total Device : 3

Local IP Address:192.1 68. 1.4

Subne t Mas k:2 55.255. 255 . 0 Gateway: 1 92. 168. 1.1 DNS：210. 21 . 196. 6

Device Nam e Dev ice Type IP Addr ess Http Port Data Port

Subnet

Product Mo del

About

Subne t Mas k

Gateway

Restore IPC Default Configuration

⑤ Install the dome and enclosure to the mounting base.

(a). Loosen the nut from the main element.

b . Run the network cable (without RJ 45 connector) through the

both elements. Then crimp the cable with RJ 45 connector.

c . Connect the cable to the hermetic connector. Then tighten the

nut and the main cover.

( )

(a)

(b)

( )

④ Secure the mounting base to the ceiling or wall with the screws provided.

Then adjust the dome to obtain an optimum view angle.

0 ~75° °

0 ~360° °

⑥ Finally, fix the camera with the fixed screw.

Fixed screw

③ Modify the IP address. The default IP address of this camera is

192.168.226.201. Click the information of the camera listed in the

above table to show the network information on the right hand.

Modify the IP address and gateway of the camera and make sure its

network address is in the same local network segment as the

computer’s. Please modify the IP address of your device according

to the practical situation.

Mac Address

IP Address

Modify Network Parameter

Modify

CE :98 :23 :75 :35 :22

192 .168 . 1 . 201

255 . 255 . 255 . 0

192 .168 . 1 . 1

Subnet Mask

Gateway

For example, the IP address of your computer is 192.168.1.4. So the

IP address of the camera shall be changed to 192.168.1.X. After

modification, please enter the password of the administrator and click

“Modify” button to modify the setting.

The default password of the administrator is “123456”.

④ Double-click the camera listed in the IP-Tool or manually enter

the IP address in the address bar of the web browser to connect IP

camera. Then follow directions to download and install the plugin.

⑤ Enter the username and password in the login interface.

The default username is admin; the default password is 123456.

450043001853 A0

Network Connection

IPC

Network Cable Network Cable

Switch

Router

Computer

● Access Through IP-Tool

① Make sure that the camera and the PC are connected to the local

network.

② Install IP-Tool from the CD and run it after installation.

Device Network Search

Immediate Re fresh

name

IPC

unknown

192.168. 226 .201

192.168. 1.2

192.168. 1.3

9008

255.255.

Modify Net wor k Parameter

Mac Addr ess

IP Addr ess

Modify

CE :98 :23 :75 : 35 :2 2

192 . 16 8 . 226 . 2 01

255 . 255 . 255 . 0

192 . 16 8 . 226 . 1

Tip: Enter the adminis tra tor password, and

then modif y the n etwork parameters.

Total Device : 3

Local IP Address:192.1 68. 1.4

Subne t Mas k:2 55.255. 255 . 0 Gateway: 1 92. 168. 1.1 DNS：210. 21 . 196. 6

Device Nam e Dev ice Type IP Addr ess Http Port Data Port

Subnet

Product Mo del

About

Subne t Mas k

Gateway

Restore IPC Default Configuration

⑤ Install the dome and enclosure to the mounting base.

(a). Loosen the nut from the main element.

b . Run the network cable (without RJ 45 connector) through the

both elements. Then crimp the cable with RJ 45 connector.

c . Connect the cable to the hermetic connector. Then tighten the

nut and the main cover.

( )

(a)

(b)

( )

④ Secure the mounting base to the ceiling or wall with the screws provided.

Then adjust the dome to obtain an optimum view angle.

0 ~75° °

0 ~360° °

⑥ Finally, fix the camera with the fixed screw.

Fixed screw

③ Modify the IP address. The default IP address of this camera is

192.168.226.201. Click the information of the camera listed in the

above table to show the network information on the right hand.

Modify the IP address and gateway of the camera and make sure its

network address is in the same local network segment as the

computer’s. Please modify the IP address of your device according

to the practical situation.

Mac Address

IP Address

Modify Network Parameter

Modify

CE :98 :23 :75 :35 :22

192 .168 . 1 . 201

255 . 255 . 255 . 0

192 .168 . 1 . 1

Subnet Mask

Gateway

For example, the IP address of your computer is 192.168.1.4. So the

IP address of the camera shall be changed to 192.168.1.X. After

modification, please enter the password of the administrator and click

“Modify” button to modify the setting.

The default password of the administrator is “123456”.

④ Double-click the camera listed in the IP-Tool or manually enter

the IP address in the address bar of the web browser to connect IP

camera. Then follow directions to download and install the plugin.

⑤ Enter the username and password in the login interface.

The default username is admin; the default password is 123456.

450043001853 A0

Vite di

ssaggio/

Fixed

screw

Vimar ELVOX - Page 56

Table of Contents

Other manuals for Vimar ELVOX

Related product manuals
