Vimar Idea 16577 - Internal Controls

8
3. Internal controls
To access to the internal controls panel, seize the equipment by
both sides (picture 3.1) and take it out to the stop.
picture 3.1
To insert the equipment again, press the two side lugs (1) on the
symbol and push it thoroughly (2), until it comes to the stop
(picture 3.2).
2
1
1
picture 3.2
