1. PROGRAMMING CONSOLE
The Vimec console connects to the V59 system via a can link. It allows programming of all machine
control parameters and allows you to run tests to check external links. The console can be used as
a human-machine interface that displays malfunctions and the related alarms.
Figure 1: Console
Backlit display, 2x16
alphanumeric characters
"ENTER" allows you to
enter the menus and the
various programming
stages
"UP" scrolls the menu
upwards
"ESC" exits from the
menus and programming
stages
"DOWN" scrolls the menu
downwards
