Page 7
2.2 "SET" menu
In the "set" submenu you can carry out the machine's adjustment in power and current. To enter it,
press ENTER, to return to the main menu press ESC.
To scroll through the programming items use UP-DOWN.
“Main” menu
Acceleration curve
Deceleration curve
Max. ascent speed
Max. descent speed
Slow zone speed
Floor zone speed
not adjustable
Zero floor approach
speed / not adjustable
Zero sensor search
speed / not adjustable
Figure 5: "SET" submenu block diagram
Up
Down
Select mode :
Set
Esc
Password
Correct?
Deceleration:
xx.xs
Max. Ascent speed:
xxx%
Max, descent speed:
xxx%
Slow zone speed:
xxx%
Floor zone speed:
xxx%
Bottom zero speed:
xxx%
Top zero speed:
xxx%
Up
Down
Up
Down
Up
Down
Up
Down
Up
Down
Up
Down
Up
Down
Enter
Enter
No
Esc
Esc
Esc
Esc
Esc
Esc
Esc
Esc
Yes
Acceleration:
xx.xs
