Features
Document no.
Article no.
VML-1520_ds rev.03 2004.08.31
VML-152
Technical data:
VML-1520
Loudspeakers
Description:
VML-1520
* Is a general purpose15 Watt horn loudspeaker
w/transformer for use on deck areas, eng. room etc.
* To be used together with ACM system stations
Rated power: 15 Watt RMS
Impedance: 20 ohm
Freq.range: 275 - 7.000 Hz
SPL at 1kHz: 106dB/1W/1m
118Db/15W/1m
Colourr/finish: Grey
Material: ABS
IP: 65
Dimensions: See drw. beside
Weight: 1,35 kg
Mounting: Bracket (stainless steel
grade 304)
Termination: Cable 0.5m
270
78
48
34,5
34,5
122
24
Mounting bracket
Holes: 3 x Ø11.0 mm
250
www.zenitel.biz\Communication & Security Systems\Zenitel Marine
