Features
Document no.
Article no.
VML-15T_ ds. rev.03 2005.07.05
VML-15T
Technical data:
VML-15T
Loudspeakers
Description:
VML-15T
* Is a general purpose 15 Watt horn loudspeaker w/
transformer for use on deck areas, eng. room etc.
* To be used together with 100V line amplifier
Rated power: 15 Watt
Tranf. tapping: See dwg. beside
Freq. range: 275 - 7.000 Hz
SPL at 1kHz: 106dB/1W/1m
118Db/15W/1m
Colour / finish: Grey
Material: ABS
IP: 67
Dimensions: See dwg. beside
Weight: 1,9 kg
Mounting: Bracket (stainless steel
Grade 304)
Termination: Cable 2.5m
34,5
34,5
122
24
Mounting bracket
Holes: 3 x Ø11.0 mm
106
145
298250
2,5m
4kohm / 2.5W
2kohm / 5W
1kohm / 10W
670ohm / 15W
COM
Tapping: By switch on LS rear side
www.zenitel.biz\Communication & Security Systems\Zenitel Marine
