Viofo WM1 - Optional Accessories; Product Diagram

1. GPS Module
2. Power On | OFF
Recording Start | Stop
3. Microphone On | OFF
4. Wi-Fi On | OFF
5. Video Protect
6. Recording Status Indicator
7. Microphone Status Indicator
8. Wi-Fi Status Indicator
9. Power In / microSD Card Reader
Mode (computer)
10. microSD Card Slot
11. Heat-dissipation Block
12. Reset Hole
13. Lens
Optional Accessories
Product Diagram
VIOFO Hardwire Kit for Car Dash Camera
INPUT:
RED
— POWER
BLACK
— GND
YELLOW
— ACC
Input: 12 / 24V; Output: 5V2A Max
43
Circular Polarizing
Lens Filter
Bluetooth Remote
Control
MicroSD card
HK4
Hardwire Kit
6
11
7
8
10
9
5
2 3
4
1
12
13
