Appendix A – Specifications
System
O.S.
Embedded Linux 3.0
Multiplex
Sixfold operation - simultaneous record, live,
playback, backup, control, & remote access
Certification
FCC, CE, etc.
Video
Format
NTSC/EIA or PAL/CCIR
Input
16-CH, BNC, 1Vp-p/75ohm
Main monitor
HDMI, with resolution up to 1920x1080,
VGA D-SUB 15-pin, with resolution 1920x1080,
BNC x 1, 1Vp-p/75ohm
Call monitor
BNC x 1, 1Vp-p/75ohm
Loss detection
Yes
Motion detection
Yes, with configurable detection area & sensitivity
Privacy mask
Yes
Audio
Input
8 RCA-jack connectors, line-in level (100mV-2Vrms)
Output
HDMI,
2 RCA-jack connectors, line-out level (up to 2Vrms)
Record
Compression
Video: H.264 Main Profile
Audio: ADPCM
Max frame rate
& resolution
NTSC – 240@960H, 360@720*480, 480@720*240, 360*240
PAL – 200@960H, 300@720*576, 400@720*288, 360*288
Mode
Manual/Schedule/Alarm/Motion
Pre-record time
0 – 10 seconds
Post-record time
0 - 60 minutes
Display
Resolution
VGA – 1920x1080, NTSC – 720x480, PAL –
720x576
Split windows
1/4/7/9/10/13/16
Frame rate
Up to 30 (NTSC) / 25 (PAL) IPS per display window
Freeze
Yes
Sequential switch
User adjustable
Digital Zoom
X2, X4
Playback
Max frame rate
& resolution
NTSC – 240@960H, 360@720*480, 480@720*240, 360*240
PAL – 200@960H, 300@720*576, 400@720*288, 360*288
Search
Smart search, Date/time, Camera, Alarm, Motion, &
Video Loss
Operation
Play, Fast Forward, Backward, Pause, Stop, Snapshot,
etc.
Remote I.E. and HEM can also Print, Snapshot
Storage
HDD
2 sets of 3.5” SATA HDDs, > 3TB for each HDD
Optional 1 set of 3.5” SATA HDD
Failure detection & privacy law supported
HDD Extension
1 eSATA connector for up to 5 eSATA HDDs
Partitions
Configurable alarm partition size
Configurable auto-overwrite or not
Backup
1 USB 2.0 port for USB 2.0 disk drives, DVD+RW,
