28
©
2005
Directed Electronics, Inc.
3-4 GROUND WHEN ARMED IN VALET (ON)/GROUND WHEN ARMED IN VALET
(OFF):
Provides On/Off programming for the Ground When Armed wire output when locking the
car while in Valet mode.
3-5 CHANNEL 3 VALIDITY (ON)/LATCHED/LATCHED, RESET WITH IGNITION/30-
SECOND/60-SECOND/90-SECOND TIMED/REMOTE START REPORT:
Channel 3 can
be programmed for these output configurations. The unit is set to the default validity output. To
change the configuration, use the two-chirp setting to toggle to the different configurations.
NOTE: Reference H2/4 discussion.
Remote Start ON Report—When programmed ON and when Channel 3 is transmitted and Zone
1 is grounded, the system will:
Zone 1 will bypass, Zone 3 will monitor and bypass input, all sensor zones will be
bypassed, the starter kill activates for anti-grind protection, the ESP will transmit Remote
Start ON to HHU (note: no transmission on this model), and the Factory Alarm Disarm
will output immediately after receiving a remote start operation.
Remote start OFF report: When programmed on, and ground on, zone 1 ceases and the system will:
Zone 3 will monitor any bypass (same as door trigger), all sensor zones will be re-
activated, the starter kill releases if the system is not armed, and the ESP will transmit
Remote Start OFF to HHU (note: no transmission on this model).
3-6 CHANNEL 3 LINKING (NONE)/ARM, DISARM, BOTH:
When programming to validity or
timed output this can be programmed to activate when arming or disarming (or both) with the transmitter.
3-7 CHANNEL 4 VALIDITY (ON)/LATCHED/LATCHED, RESET WITH WITH
IGNITION/30-SECOND/60-SECOND/90-SECOND TIMED:
Refer to discussion for H2/4.
3-8 CHANNEL 4 LINKING (NONE)/ARM, DISARM, BOTH:
See Feature 3-6.
3-9 CHANNEL 5 VALIDITY (ON)/LATCHED/LATCHED, RESET WITH WITH
IGNITION/30-SECOND/60-SECOND/90-SECOND TIMED:
Refer to discussion for H2/4.
3-10 CHANNEL 5 LINKING (NONE)/ARM, DISARM, BOTH:
See Feature 3-6.
3-11 CHANNEL 6 VALIDITY (ON)/LATCHED/LATCHED, RESET WITH WITH
IGNITION/30-SECOND/60-SECOND/90-SECOND TIMED:
Refer to Feature 3-5.
