2005
Directed Electronics, Inc.
13
Relay Harness Wiring Instructions
H2/A BLACK/WHITE input to on-board interior light illumination relay #87
This wire determines what the output polarity of H1/4 will be. If the door pin circuit is negative,
connect to chassis ground. If the door circuit is positive, connect to a fused 12V source.
H2/B – H2/G power door lock wires
The system has door lock relays on-board, and can directly interface with most electric power door
lock systems drawing 30 amps or less.
Immobilizer Wire Connection Guide
Immobilizer Wiring Diagram
___
___
___
Immobilizer Wiring Guide
The starter immobilizer harness can be installed as a normally open or normally closed circuit by
connecting the desired side of the three-wire immobilizer. Locate the starter wire, then cut it and
make connections as described in the following diagram. Connect wire C to the end of the wire that
is still connected to the ignition switch; connect A or B wire to the end of the wire that continues
to the vehicle’s starter circuit.
NNoottee
: Factory default setting is normally closed, if wired for normally open you must change the pro-
gramming.
GREEN/WHITE Starter - Common (key side)
GREEN Starter - Normally Open (motor side)
GREEN/BLACK Starter - Normally Closed (motor side)
A
B
C
IMPORTANT! The H2/A wire is not required for wiring the door locks. Depending on
the type of door lock system, there may be additional wires in the Door Lock Harness
(H2) that are not required to be used in wiring the door locks.
