Viper 3000 Installation Guide

©
2005 Directed Electronics, Inc. 37
System will not passively arm until it is remotely armed and then disarmed.
➤ Are the door inputs connected? Is a blue H1/7 wire connected to the door trigger wire in the
vehicle? Either the green H1/5 or the violet H1/6 should be used instead.
Door input does not respond with the progressive trigger, but with immediate full alarm.
➤ What zone does the LED indicate? If the LED indicates that the impact sensor caused the
trigger, the sensor may be detecting the door opening. Reducing the sensitivity or relocating
the sensor can often solve this problem. If the LED indicates that the door caused the trigger,
you may have programmed the progressive door trigger off. (See Feature 2-4 in the
Feature
Descriptions
section of this guide.)
The Valet button doesn’t work.
➤ Is it plugged into the correct socket? Check the System Features Learn Routine for the
programmed Valet pulse count.
Status LED doesn’t work.
➤ Make sure that it is plugged in. (See Plug-In Harnesses section of this guide.) Is the LED
plugged into the correct socket?

Viper 3000 Specifications

General

Model	Viper 3000
Category	Car Alarm
Remote Control	Yes
Number of Remotes Included	2
Door Lock Control	Yes
Trunk Release	Yes
Panic Mode	Yes
Valet Mode	Yes
Remote Start Ready	Yes
Range	1/4 Mile
