PARTS LIST
73
AS4335C CHASSIS ASSEMBLY
Kit Item Part No. Description Qty
K1/K2/K4
1 BUSHING 5
K1/K2/
K4/K5/K8
2 WASHER 10
K1 3 SCREW M8x25 3
4 VS15101 BRUSH LIFTING SUPPORT 1
K2/K4 5 SCREW M8x30 2
K2/K3/K4
6 NUT M8 3
K3/K5 7 SCREW M8x50 2
K3 8 STEPS BUSHING 1
K4 9 VS15102 FRONT PEDAL BRUSH LIFTING 1
K5 10 VS10613 PEDAL LEVER GASKET 1
K5 11 VS15103 BACK PEDAL BRUSH AND SQUEEGEE LIFTING 1
K5 12 WASHERφ12*φ24*2 1
K5 13 RESET SPRING 1
K5 14 BUSHING 1
K1/K4/
K5/K8
15 WASHER DIAMETER 8MM 9
K6 16 WHEEL SHAFT 2
K6 17 VF80115B WHEEL 6 INCH 2
K6 18 NUT M16 2
19 VS15100 CHASSIS 1
K7 20 SPRING WASHER 4
K7 21 WASHER DIAMETER 6MM 4
K7 22 SCREW M6*25 4
K8 23 VS15327 3.5 INCH CASTER 1
K8 24 SCREW M8x20 4
25 VS15014 110V AC SOLENOID VALVE 1
K9 26 SCREW M4*10 4
K9 27 VV10114 CLAMP 3/8" 6
K9 28 HOSE Ø 20MM L400mm 1
K9 29
HOSE WITH SPRING
1
K9 30
OULET HOSE Ø 20MM 1
K10 31
FILTER BASE 1
