PARTS LIST
74
AS4335C CHASSIS ASSEMBLY
Kit Item
Part No. Description Qty
K10 32 VF90608 FILTER NET 1
K10 33 VF90607 O-RING 1
K10 34 VF90603 FILTER COVER 1
K11 35 STRAIGHT CONNECTOR 1
K11 36 VF80361 WATER VOLUME REGULATING VALVE 1
K11 37 RIGHT ANGLE CONNECTOR 1
K2 38 PA WASHER 2
K6 39 BUSHING1 2
K1 VS15422 SCREW KIT 1 3
K2 VS15423 SCREW KIT 2 1
K3 VS15424 FORNT PEDAL BRUSH LIFTING SCREW KIT 1
K4 VS15425 SCREW KIT 3 1
K5 VS15426 BACK PEDAL BRUSH LIFTING KIT 1
K6 VS15427 WHEEL 6 INCH KIT 2
K7 VS15428 SCREW KIT 4 1
K8 VS15429 3.5 INCH CASTER KIT 1
K9 VS15433 SOLUTION HOSE KIT 1
K10 VF90621 FILTER KIT 1
K11 VF90624 WATER VOLUME REGULATING VALVE KIT 1
