Virginia Controls MH-3000 User Manual

Virginia Controls, LLC MH-3000 User Manual, 1_03C10-VC Page 100
7. Controller Nomenclature
SYMBOL
DESCRIPTION
PARTS LIST
ITEM NO
C
DOOR CLOSE RELAY (in MODSS on top of the car, if used)
A5
DL
DOWN LEVEL RELAY (on Printed Circuit board)
A1
DOLX
DOOR CHECK RELAY (on Printed Circuit board)
A1
DZ
DOOR ZONE RELAY (on Printed Circuit board)
A1
ESB
EMERGENCY STOP SWITCH BY-PASS RELAY (on Printed Circuit board)
A1
FSD
FAST SPEED DOWN RUN RELAY (on Printed Circuit board)
A1
FSU
FAST SPEED UP RUN RELAY (on Printed Circuit board)
A1
IAS1-2
INSPECTION ACCESS RELAYS (on Printed Circuit board)
A1
INS
INSPECTION RELAY (on Printed Circuit board)
A1
O
DOOR OPEN RELAY (in MODSS on top of the car, if used)
A5
PM
STARTER (ACROSS THE LINE START)
B4/B7
PMP
PUMP MOTOR PILOT RELAY (110VDC) (on Printed Circuit board)
A2
RU
MOTOR RUN CONTACTOR (WYE-DELTA START)
B1/B6
SP1-5
SPARE RELAYS (Function varies per job) (on Printed Circuit board)
A1
STR
MOTOR START CONTACTOR (WYE-DELTA START)
B1/B6
TRU
WYE-DELTA MOTOR RUN RELAY (WYE-DELTA START) (on Printed Circuit board)
A1
TRUP
WYE-DELTA MOTOR RUN TIMER (WYE-DELTA START) (on Printed Circuit board)
A4
UL
UP LEVEL RELAY (on Printed Circuit board)
A1
VR
VOLTAGE RELAY (OPTIONAL) (on Printed Circuit board)
A1
