Virginia Controls, LLC MH-3000 User Manual, 1_03C10-VC Page 33
5.5 Microprocessor
5.5.1 CPU
LCD Display
CPU Status
Reset Button LEDs
Termination
Jumpers
Group
Communication Keypad
Connector
I/O Board
Communication
Connector
Battery S2 Slide Sws
12VDC
Power EPROM
Supply Socket
