Virginia Controls, LLC MH-3000 User Manual, 1_03C10-VC Page 47
5.6.2 Wye-Delta Starting
Connect Building
Supply Power
Here
Run Contactor
Start Contactor
Mechanical
Interlock
Overload
Relay
Connect Motor
Leads Here
