Virginia Controls, LLC MH-3000 User Manual, 1_03C10-VC Page 101
8. Parts List
ITEM
DESCRIPTION
MANUFACTURER
PART NO
RELAYS
A1
4PDT, 120VAC, PLUG-IN RELAY
Idec or equivalent
RU4S-A110
A2
4PDT, 110VDC, PLUG-IN RELAY
Idec or equivalent
RU4S-D110
A3
SURFACE MOUNT RELAY SOCKET
P&B
27E894
A4
TIMER, 0-102.3 SECONDS
AIRTRONICS
THCU102S3E
A5
3PDT, 120VAC, PLUG-IN RELAY
P&B or equivalent
KUP-14A35
CONTACTORS, STARTERS, OVERLOAD
B1
Y-D REVERSING CONTACTOR (NEMA)
SQD
S__0__V02
B2
3 POLE THERMAL OVERLOAD (NEMA)
SQD
SE0____
B3
ACROSS-THE-LINE STARTER (NEMA)
SQD
S__0__V02
B4
HEATERS FOR 3 POLE OVERLOAD (NEMA)
SQD
(Types: B, CC, DD)
B5
Y-D REVERSING CONTACTOR (IEC)
SQD/Telemechanique
LC2-____G6
B6
ACROSS-THE-LINE STARTER (IEC)
SQD/Telemechanique
LC1-____G6
B7
3 POLE OVERLOAD (IEC)
SQD/Telemechanique
LR____
TRANSFORMERS, FUSES, TERMINALS
C1
460-230-208/230-115, (600VA & 300VA)
SQD
9070K____D48
C2
250V INSTANTANEOUS FUSE
BUSSMAN
TYPE BAF
C3
250V FUSEHOLDER
CURTIS
PW1F
C4
TRACK FOR 250V FUSEHOLDERS
CURTIS
SW192
C5
3 POLE TERMINAL, 600V, 50AMP
CURTIS
3PSWT
C6
MOUNTING TRACK FOR TERMINALS
CURTIS
SW192
MICRO-PROCESSOR
D1
MICROPROCESSOR CPU BOARD
V.C.
MH3000-CPU
D2
16-IN/16-OUTPUT MODULE
V.C.
MH3000-16IO
D3
KEYPAD
V.C.
MH3000-KEYPAD
D4
LCD SCREEN
V.C.
MH3000-LCD
D5
CPU BATTERY
PANASONIC
CR2032
MISCELLANEOUS COMPONENTS & HARDWARE
E1
PRINTED CIRCUIT BOARD
V.C.
MH-4
