Virginia Controls MH-3000 User Manual

Virginia Controls, LLC MH-3000 User Manual, 1_03C10-VC Page 40
5.5.2 Input/Output Boards
Refer to the picture or diagram of the IO boards shown below to identify the key
components.
Removable
Terminals
Commons
I/O numbers
Programming
Port
Input LEDs Output LEDs
with number with number
below LED below LED
I/O Comm Address
Connector (IN) Switches
Status LED
12VDC I/O
Incoming Communication
Power Connector (OUT)
Input LEDs Output LEDs
with number with number
above LED above LED
