Vision Engineering EVO Cam User Manual

ASSEMBLY
www.visioneng.com/support
3
Transmitted substage illuminator
(option)
` Remove the stage cover plate
u
and thread the
lead
v
through the stand base.
` Locate the illuminator
w
into the stage base and
secure it with the 2 screws
x
.
` Carefully lay the Ergo stand on to its side and thread
the lead through the base as shown.
` Push the cable grommet
y
into the stand.
` Turn the Ergo stand upright and replace the illuminator
diffuser
z
shiny side up, surround
{
and glass
|
.
` Once EVO Cam is installed on the stand (see page 4)
connect the sub-stage power cable to the EVO Cam.
If assembling the optional glare reducing lter,
this needs to be placed between the diffuser and
the surround.
u
x
v
w
|
{
z
y
