Vision MAX Pro User Manual

Vision Max Pro User Manual174
© 2015 Vision Engraving Systems
Replacing the Drive Belt
The drive belt will need replacement periodically, depending on usage. To remove the drive belt, lower
the spindle and roll the front edge of the drive belt over the lip of the spindle pulley.
Remove the old belt and place the new belt on the motor pulley as shown.
