Vision MAX Pro User Manual

Example Jobs 97
© 2015 Vision Engraving Systems
4.1.3.1 Example Job 3 - Burnishing
In this example, another feature in the Vision Software will be introduced. We will create a Plate Object
in order to create multiple items with different text engraved on a single 7.85 x 5.4 inch (199.4 x 137.2
mm) piece of coated brass (also known as black brass or trophy brass). The plate will use a text import
function from an external text file that will be copied into a plate template and the Vision software will
automatically format the imported text.
Begin by selecting the Plate Size Icon and setting the engraving area to a custom plate size with a 7.85
x 5.4 inch area.
To create the Plate Object, select Layout Plate Object Create Plate from the top toolbar menu.
