REAR PANEL CONNECTIONS
REAR PANEL CONNECTIONS
EXTERNAL MONITOR OUT
REMOTE CONTROL JACK
RS-422 OUTPUT
PLUG FROM COM 1 PORT
SIGNAL +
SIGNAL -
NOT USED
!
CAUTION: Be careful of the polarity of the RS-422 lines
Reversing the polarity can damage some equipment. If you have
Questions about what equipment will work with you DVR’s
RS-422 contact your dealer.
