2. InCam-HG Encoder Transmitter Introduction
The Vislink INCAM-HG is a fully integrated HEVC 4K UHD, HDR-ready
wireless system, designed for the Grass Valley LDX 86N 4k-RF 4K UHD
camera.
The INCAM-HG offers full broadcast quality encoding at 4K UHD, 1080p,
1080i and 720p with camera control.
The unit utilizes user-changeable RF modules for rapid, in-field, swap
outs.
2.1. InCam Matrix
The InCam-HG unit comprises of two parts with the main chassis and
interchangeable RF unit, meaning the unit is flexible to changing needs.
Unit Number
Max
O/P
Power
(mW)
Freq
RF/UHF
Module
View-
Back
Battery
Plate
INHG-ASSY-7002
250
1.95-2.7 GHz
HCAM-ASSY-5501
✓
IDX
INHG-ASSY-7003
100
5.6-6.0 GHz
HCAM-ASSY-5506
✓
IDX
INHG-ASSY-7004
100
6.8-7.5 GHz
HCAM-ASSY-5505
✓
IDX
INHG-ASSY-7005
100
6.425-7.125 GHz
HCAM-ASSY-5504
✓
IDX
INHG-ASSY-7006
250
1.95-2.7 GHz
HCAM-ASSY-5501
✓
A/B
INHG-ASSY-7007
100
5.6-6.0 GHz
HCAM-ASSY-5506
✓
A/B
INHG-ASSY-7008
100
6.8-7.5 GHz
HCAM-ASSY-5505
✓
A/B
INHG-ASSY-7009
100
6.425-7.125 GHz
HCAM-ASSY-5504
✓
A/B
INHG-ASSY-7010
250
1.95-2.7 GHz
HCAM-ASSY-5501
X
IDX
INHG-ASSY-7011
100
5.6-6.0 GHz
HCAM-ASSY-5506
X
IDX
INHG-ASSY-7012
100
6.8-7.5 GHz
HCAM-ASSY-5505
X
IDX
INHG-ASSY-7013
100
6.425-7.125 GHz
HCAM-ASSY-5504
X
IDX
INHG-ASSY-7014
250
1.95-2.7 GHz
HCAM-ASSY-5501
X
A/B
INHG-ASSY-7015
100
5.6-6.0 GHz
HCAM-ASSY-5506
X
A/B
INHG-ASSY-7016
100
6.8-7.5 GHz
HCAM-ASSY-5505
X
A/B
INHG-ASSY-7017
100
6.425-7.125 GHz
HCAM-ASSY-5504
X
A/B
INHG-ASSY-7018
250
3.2-3.9 GHz
HCAM-ASSY-5502
✓
IDX
INHG-ASSY-7019
250
3.2-3.9 GHz
HCAM-ASSY-5502
✓
A/B
INHG-ASSY-7020
250
3.2-3.9 GHz
HCAM-ASSY-5502
X
IDX
INHG-ASSY-7021
250
3.2-3.9 GHz
HCAM-ASSY-5502
X
A/B
INHG-ASSY-7022
100
4.45-5.0 GHz
HCAM-ASSY-5503
✓
IDX
INHG-ASSY-7023
100
4.45-5.0 GHz
HCAM-ASSY-5503
X
IDX
Table 2-1 InCam Matrix Table
