Vislink InCam-HG User Manual

Template Operators Manual
InCam Setup
Issue No: 1 Page: 38
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
7.3. Video Format Configuration
The Video Format requires setting in the camera menu and InCam-HG
menu
Camera Menu:
• Installed Level> User3
• Production Setup> Video Mode>
InCam-HG Menu:
• Encoder> Settings> Format
7.3.1. Video Combinations
Camera Video Mode
InCam-HG
Note
4K/(50/59)
UHDp – 2SI
1080p(50/59)
1080p
1080i(50/59)
1080i
720p(50/59)
720p
1080p(150/170)
UHDp – Quad
Slow Motion (HFR)
Table 7-2 Video Combinations
7.4. Audio Combinations
The Analogue audio input from the Grass Valley LDX Camera Head is
embedded on channel 1 & 2 (duplicated) into the InCam.
The camera also has a Test Tone embedded onto Channel 7.
The InCam is configurable to use either the SuperSlot or Rear External
Audio 2 for additional audio.
7.4.1. SuperSlot
The SuperSlot embeds one AES audio pair from the WisyCom Wideband
Audio Receiver onto Channel 3&4,
InCam Audio settings:
o Audio 1, Pair 1,
▪ Embedded – Group 1, Pair 1 (Camera analogue Audio)
o Audio 1, Pair 2,
▪ Embedded – Group 1, Pair 2 (SuperSlot AES Pair)

Vislink InCam-HG Specifications

General

Brand	Vislink
Model	InCam-HG
Category	Transmitter
Language	English
