Template Operators Manual
InCam Transmitter Connector Descriptions
Issue No: 1 Page: 18
Ref: INHG-ASUM-70XX Copyright © 2020 IMT and Vislink are Vislink Technologies Inc. companies
4.2. Modulator Input / Output Connectors
4.2.1. COFDM TX RF
100mW into 50Ω – switchable. 10, 50, 100 and 250mW fixed power
settings, and a user-adjustable mode between zero and 24dBm.
NOTE: 250mW is for use in FCC regulatory regions only.
50Ω chassis mounted ‘N’ type bulkhead socket.
L3421 TX Omni Spring 3 dBi 1.95-2.7GHZ
L3423 TX Omni Spring 3 dBi 1.95-2.7GHZ
(Extra Long)
L3424 TX Omni Spring 3 dBi 3.0-3.7GHZ
Table 4-1 OFDM Antennas
WARNING: There should always be an antenna connected to the N-type
connector when the unit is powered.
4.2.2. UHF RX RF
SMA connector for UHF receive antenna: 410-490MHz.
Antenna: L0018-4145 410-450MHz SMA (M) Red Cap
Antenna: L0018-4549 450-490MHz SMA (M) Blue Cap
4.3. Modulation Options
The modulator operates as one of three main types:
1. Single Pedestal LMST(S)
2. Dual Pedestal LMST(D)
3. DVB-T
Modulation options are selected in the MODULATOR > Modulation menu.
Here, you select either LMST or DVB-T.
Select the Bandwidth from MODULATOR > Bandwidth menu.
NOTE: In LMST(D) mode, the bandwidth shown is the combined width of
the two pedestals.
