3. Specifications
3.1. Physical
Feature
Description
Dimensions
212 x 213 x 141 mm
Weight
2.8kG
Temperature
-20
o
C to 45
o
C (-4
o
F to 113
o
F)
Power Connector
4-pin XLR or Battery
Power Consumption
Nominally 30W in standard
configuration (with L1750-1927)
Table 3-1 Physical Spec
3.2. Inputs
Feature
Description
Audio
Camera XLR - Analogue
WisyCom, Super Slot - AES
External XLR - Analogue
UHF Receiver
410 to 490MHz range
FocalPoint camera control
compatibility
View-Back Receiver
H.264 Diversity Receiver
with switchable Viewfinder
Table 3-2 Inputs Table
3.3. Output
Feature
Description
Frequency Band
See the InCam Matrix table.
Transmit Power
10 to 250mW (or add barrel booster option)
RF Module specific
Transmit Antenna
Omni-directional 3 dBi gain (nominal)
Frequency Selection
Up to 32 preset channels for tuning
Modulation
COFDM DVB-T or LMS-T
Modulation Modes
DVB-T:
- QPSK, 16QAM, 64QAM
- FEC: 1/2, 2/3, 3/4, 5/6, 7/8
- Guard Interval: 1/32, 1/16, 1/8, 1/4
LMS-T:
- QPSK, 16QAM
- FEC: 1/2, 2/3, 3/4, 5/6, 7/8, 9/10, 14/15
- Guard Interval: 1/16, 1/8
Data Rate
DVB-T 4.98 to 31.7 Mbit/s
LMS-T up to 43 Mbit/s bandwidth dependent
(licensed option)

Vislink InCam-HG Specifications

General

Brand	Vislink
Model	InCam-HG
Category	Transmitter
Language	English
