3. Specifications
Dual Diversity Receiver Head Unit
NOTE: Vislink may alter these specifications its own discretion or to meet customer
requirements.
Feature
Details
Frequency Band
1.3 to 13GHz
Tuning Range
Up to 700MHz.
Frequency Selection
Up to sixteen pre-set channels, or tuning in 1MHz steps via front
panel control
Receiver Noise Factor
4dB (nom.)
Receive Antenna
Compatible with all Gigawave antennas
Bandwidth
Filtered for COFDM 8MHz bandwidth
IF Frequencies
1
st
IF in the range 800MHz nom. (depending on frequency band)
2
nd
IF 60 and 80MHz or 70MHz (system dependent)
Control and Monitoring*
Comprehensive remote control and monitoring via Ethernet
port/Web browser
Power Supply*
Triax powered, +48 VDC (nominal), 20 to 48 VDC max. derived
from the associated RX control unit
Directly powered, external input +20 to 50 VDC
Power consumption 70 to 110 Watts (varies with Triax cable
length and options)
Mechanical Interface
Mast, scaffold and special mounts available.
Size
150 x 111 x 152mm
Weight
1.6kg
Environmental
Safe use: -20° to +50°C
To spec: - 10° to +45°C
Altitude: 4500m
Humidity: 95% long term
Table 3-1 Dual Diversity Receiver Specification
NOTE: * indicates that one of the options is applicable
