RCD9 Receiver Operators Manual
Dual Diversity Receiver Head Unit
Issue No: 1 Page: 15
Ref: RCD9-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink
5. Dual Diversity Receiver Head Unit
Connectors and Pin Outs
5.1.1. RF Inputs
Connector type: N type
5.1.2. Triax Connector
Connector type: LEMO connector FBD.4E.675.CTL
Input range: +48 VDC nominal (20V to 48 VDC)
NOTE: The Dual RF Head Unit may derive its power either from the Triax (normal method),
or from the separate Lemo, see Section 5.1.3.
5.1.3. DC Input
Connector type: LEMO connector EGG-1K-303-CLL
Input range: 20V to 50VDC
Pin
Function
1
0V / Gnd
2
NC
3
+20 to +50V DC
Table 5-1 DC Input Pinouts
5.1.1. Remote
Connector type: LEMO connector EGA 0K 307 CLL
A seven-pin connector is used to provide an analogue voltage representing the received RF
level (0 to 5V into a load of 5k Ohms or more). This provides a convenient AGC metering
aid for alignment of the antenna. The same connector has an RS485 serial interface for
factory set up.
Pin
Function
Direction
1
0v
-
2
RF level voltage
Out from unit
3
NC
NC
4
RS485 Tx+
Out from Unit
5
RS485 Tx- / RS232 Tx
Out from Unit
6
RS485 Rx-
Into Unit
7
RS485 Rx- / RS232 Rx
Into Unit
Table 5-2 Remote Pinouts
