4.3.2. DC Power
Input range: 12V to 36V DC.
This DC input provides power to both the MVL-HD2 Receive Control unit and the Receive
Head unit(s) via the Triax cable.
Connector type: 4-Pin XLR Male
Pin
Function
1
0V / Gnd
2
NC
3
NC
4
+12 to 36V DC
Table 4-2 Mains Power Pinouts
4.3.3. ANALOGUE VIDEO OUTPUT
Connector type: HD-BNC
Output of Composite video (CVBS) when the system is in SD mode.
HD down-converted to analogue (monitoring quality) when the system is in HD mode.
4.3.4. SDI/ASI OUTPUTS (2)
Two-connector type: HD-BNC
The connectors can be independently configured to provide either HD or SD SDI video
(with embedded audio / Dolby audio) or ASI. See Section 6.7.3.2 for details of output
selection.
