Vislink RCD9 - 2;4-Way Diversity Receiver Control Unit

RCD9 Receiver Operators Manual
Specifications
Issue No: 1 Page: 8
Ref: RCD9-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink
2/4-way Diversity Receiver Control Unit
Feature
Details
Input Connectors
2x or 4x mini Lemo Connectors, system dependent
Triax Separation
Up to 600m
Demodulation
2-way or 4-way Maximum Ratio Combining Diversity Reception
COFDM DVB-T 2k
Demodulation Modes
QPSK, 16QAM, 64QAM
FEC:
1
/
2
2
/
3
3
/
4
5
/
6
7
/
8
Guard interval:
1
/
32
1
/
16
1
/
8
1
/
4
Data Rate
4.98 to 31.7 Mbit/s (automatic selection)
Bandwidth
6, 7, 8 MHz
Decoding Modes
SD/HD MPEG-4/ H.264, SD/HD MPEG-2 (automatic selection)
Video Formats HD/SD
1080p
1920 x 1080
1080i
1920 x 1080
720p
1280 x 720
480i (NTSC)
720 x 480
576i (PAL)
720 x 576
Digital
SDI 3G
SMPTE-425M
SDI HD
SMPTE-292M (299M)
SDI SD
SMPTE-259M (272M)
HDMI
V1.3a
Analogue
Composite (PAL/NTSC)
HD to down-converted SD composite, monitoring quality.
Audio Outputs
Digital
2 x AES3/EBU
2 x stereo SDI embedded
Dolby D (AC3) and Dolby E pass-through via SDI embedded and
AES
Analogue
2 x stereo / 4 x mono outputs
Latency
Automatic selection down to sub 1 frame (20ms), transmitter
encoding profile dependent
ASI/SDI Output
ASI transport stream (qty2) 188 byte
TSoIP
UDP, RTP, Unicast and Multicast Ethernet IP protocol
User Data Output
1200 to 230,400 baud “User Data” channel
Monitoring
Video picture monitoring on the full color LCD front panel display
Comprehensive control and monitoring menu via front panel
control
COFDM demodulator parameters
RF Received signal level (dBm and bar graph)
C/N, MER, BER (dB and bar graph)
Internal lock alarms
Remote Control
Remote control and monitoring via Ethernet port
USB Upgrade Port
USB port for internal software upgrade
Power Requirements
Universal supply 100-240VAC (auto sensing) plus 12 - 36VDC
(75W)
