RCD9 Receiver Operators Manual
MVL-HD3 Diversity Control Unit
Issue No: 1 Page: 11
Ref: RCD9-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink
4. MVL-HD3 Diversity Control Unit
Front Panel Layout
Figure 4-1 Front Panel Layout
Rear Panel Layout
Figure 4-2 Rear Panel Layout
Connectors and Pinouts
4.3.1. Mains Power
Input range: 100V to 240VAC 50/60Hz.
Replacement type of the mains fuse: 5x20mm, Time Lag 3.15A, 250V
Fuse breaking capacity: UL: 10kA @125V AC, IEC: 1.5kA @ 250V AC.
Connector type: Fused IEC Inlet
Table 4-1 Mains Power Pinouts
CAUTION: If no earth is present on the AC mains lead, connect an independent earth to the
MVL-HD3 control unit. A fixing point is provided on the rear panel for this
purpose. For further power information for the unit, see AC supply connection
and protective earth in Section 1.1 above.
