4.3.7. USB Port
This port may be used to allow software in the Receiver control unit to be updated. Please
see Section 6.7.6.6.
4.3.8. Ethernet Remote (rear panel connector)
Connector type: RJ11
The Ethernet port on the connector panel may be used for remote control and monitoring
of the receiver.
4.3.9. HDMI
Connector type: Type C HDMI 1.3a
4.3.10. TSoIP
Connector type: RJ11
The TSoIP Ethernet port allows easy transportation of encapsulated ASI over an IP Ethernet
networking system.
4.3.11. Option (front panel connector)
Connector type: LEMO 7way EGG.1B.307.CLL
This connector is available for future application.
4.3.12. Data (front panel connector)
Connector type: LEMO connector EGG.1B.307.CLL
Allows ‘User Data’ RS 232 or R485 to be output from the ASI Transport stream.
Pin
Function
Direction
1
0v
NC
2
User Data Tx -n RS232
Out from Unit
3
User Data Rx –n RS232
Into Unit
4
User TX p RS485
NC
5
User TX n RS485
NC
6
User RX_p RS485
NC
7
User RX_n RS485
NC
Table 4-5 Data Pinouts
4.3.13. Triax
Connector type: LEMO connector FFA.2S.675.CTA C87Z
Two or four triaxial connectors carry DC power, 60MHz/80MHz IF and serial control /
status data between the Diversity Unit and Head units.
