RCD9 Receiver Operators Manual
Control Menus and Receiver Operation
Issue No: 1 Page: 24
Ref: RCD9-ASUM-7001 Copyright © 2017 IMT Ltd, trading as Vislink
Normal
Inverted
Inputs
Demodulator
RF Inputs
2-Input
4-Input
Diversity Mode
Input 1 Only
2-Way MRC
4-Way MRC
2x2 Switched
Triax Cards
Single Triax
Dual Triax
Decoder
ASI Input
Demodulator
Ext. ASI
Ext. IP
Signal Loss
Last Image
Blue Screen
Outputs
Analogue
A. Level Pair 1
A. Impedance
Low
600 
Ports
User Data
PID
Format
Interface
RS232
RS485/422
Baud Rate
Parity
Data Bits
Ethernet
State
