14
Operation
RECIRCULATION VENT COVER
□ For installations which are recirculating the air exhaust, the
recirculation vent cover must be removed.
□ Remove the recirculating vent cover by removing the two
mounting screws with a screwdriver.
NOTE: For installations which are venting out the roof or
wall, the recirculating vent cover must remain in place.
Do not remove as unit will not perform properly.
□ To complete the installation, go to “Installing power supply
cable” section.
□ The range hood is designed to remove smoke, cooking vapors
and odors from the cooktop area. For best results, start the
hood before cooking and allow it to operate several minutes
after the cooking is complete to clear all smoke and odors from
the kitchen.
□ The hood controls (1) are located on the top of the range hood
(A).
1
A
RANGE HOOD CONTROLS
□ Operating the light
□ Push the light switch (1) to the right to turn the light On.
□ Push the light switch (1) to the left to the turn the light Off.
□ Operating the fan
□ Push the fan switch (2) to the left for Low speed.
□ Push the fan switch (2) to the right for High speed.
□ Push the fan switch (2) to the middle for Off.
WARNING: To reduce the risk of re or electrical shock
disconnect from power supply before cleaning.
IMPORTANT: Clean the hood and grease lters
frequently according to the following instructions. Replace
grease lter before operating hood.
IMPORTANT: When cleaning surfaces, do not use soap-
lled scouring pads, abrasive cleaners, cooktop polishing
creme, gritty washcloths or paper towels. To avoid
damage to the stainless steel, do not use cleaners that
contain chlorine.
CLEANING METHOD:
□ Use warm water with liquid detergent or all purpose cleaner
and soft cloth to clean outside surfaces.
□ Rinse with clean water and dry with soft, lint-free cloth.
□ Use glass cleaner to remove ngerprints.
NOTE: On stainless steel nish, clean in direction of
stainless steel brush to avoid scratching or damaging
the surface.
Care and Cleaning
