Network Video Decoder SVP-1000 Full Manual
36
APPENDIX C.
Technical Specification of SVP-1000
Video Decompression Standard: MPEG-4
Bit Rate: Max. 2Mbps
Frame Rate: Max. 25/30 fps
Output: Analog Composite, 1Vp-p, 75 Ohms, PAL or NTSC
Audio Decompression Standard: G.711, G.726
Bit Rate: 64Kbps, 32Kbps
Sampling Frequency: 8 KHz
Input: Microphone Input, -65 dB@600 Ohms
Output: Line Output, -10 dB@600 Ohms
Network
Protocols : TCP, IP, UDP, HTTP
Configuration : WEB Browser
Ethernet : 10/100Base-T, Auto Sensing
Connector Video Output : 1 x BNC Connector for Composite
Audio Input : 1 x 3.5mm Phone Jack
Audio Output : 1 x 3.5mm Phone Jack
COM : 2 x Terminal Block for RS-485 and RS-232
Ethernet : RJ-45 Connector
Power Input Voltage : DC 12V/1A
Power Consumption : 4 Watts
Environment
Operating Temperature : 0 – 50℃(32 - 122℉)
Humidity : 20 – 80% non-condensing
Dimension
Weight
Dimension: 112(W)mmX30(H)mmX113(D)mm
Weight: 330g
* The DC Power Adaptor is optional (not included in this packet)
Seorim Technology Co., Ltd
#1001, daerung technotown vi, 493-6, gasan-dong, kumchun, seoul, korea, 153-803
Tel: +82-2-2108-5860
Fax: +82-2-2108-5869
E-mail: sales@seorimtech.com
http://www.seorimtech.com
