Ventilation
If you are mounting the display in an enclosure, leave sufficient space on all sides between it and surrounding objects, as
shown in Figure 3-1. This allows heat to disperse, maintaining the proper operating temperature.
Figure 3-1. Ventilation Requirements for Enclosure Mounting
Wall
50 mm (2 " )
50 mm (2 " )
Wall
50 mm (2 " )
50
mm
(2
"
)
50
mm
(2
"
)
