Supported Timings
Table 7-2 lists the signal types supported by each input on the display.
Table 7-2. Supported Timings By Input
Timing fH (kHz) fV (Hz)
Dot
clock
(MHz)
HDMI PC DVI DisplayPort
VESA
VGA 640x480
31.469
59.94
25.175
O
O
O
O
SVGA 800x600
35.156 56.25 36 O O O O
37.879 60.317 40 O O O O
XGA 1024x768
48.363
60.004
65
O
O
O
O
WXGA1360x768 47.712 60.015 85.5 O O O O
1280 x 720
44.444 59.98 64 O O O O
44.772
59.86
74.5
O
O
O
O
1280 x 768
47.776 59.87 79.5 O O O O
47.396
59.995
68.25
O
O
O
O
1280 x 800
49.306 59.91 71 O O O O
49.702 59.81 83 O O O O
SXGA
1280x1024
63.981
60.02
108
O
O
O
O
SXGA+ 1400 x1050
64.744 59.95 101 O O O O
65.317 59.98 121.75 O O O O
1440 x 900
55.469
59.901
88.75
O
O
O
O
55.935 59.88 106.5 O O O O
WSXGA+ 1680 x1050
64.674 59.883 119 O - O O
65.29
59.954
146.25
O
-
O
O
UXGA 1600 x 1200 75 60 162 O O O O
1920 x 1080 66.587 59.93 138.5 O O O O
EDTV
480p
31.5
60
27.03
O
-
O
O
576p 31.25 50 27 O - O O
HDTV
720p
1280x720
37.5 50 74.25
O - O O
44.995
59.94
74.176
O
-
O
O
45 60 74.25 O - O O
1080i
1920x1080
28.13
50
74.25
O
-
O
O
33.716
59.94
74.176
O
-
O
O
33.75 60 74.25 O - O O
1080p 1920x1080
67.433
59.94
148.352
O
-
O
O
67.5 60 148.5 O - O O
