Table 6-2. Serial Commands (continued)
Main Item Control Item CMD Type Value
(DEC)
Reply
(DEC)
Content CMD (HEX)
Other Control Scaling ASP W/ R 01 01 Full Screen 41 53 50
02 02 Pillar Box
04 04 Auto
Baud Rate
Adjustment
BRA W/ R 00 00 115200 42 52 41
01 01 38400
02 02 19200
03 03 9600
Other Control RCU W 00 00 MENU Key 52 43 55
01 01 INFO Key
02 02 UP Key
03 03 DOWN Key
04 04 LEFT Key
05 05 RIGHT Key
06 06 ENTER Key
07 07 EXIT Key
Other Control ALL W 00 00 Reset All 41 4C 4C
KLC W/ R 00 00 Un-lock Keys 4B 4C 43
01 01 Lock Keys
SER R 13 bytes Rea d Serial Number 53 45 52
MNA R 13 bytes Rea d Model Name 4D 4E 41
GVE R 6 bytes Read Firmware Version 47 56 45
RTV R Current
value
Rea d RS-232C Table
Version
52 54 56
WFS W/ R 00 00 Wake Up From Sleep =
VGA Only
57 46 53
01 01 Wake Up From Sleep =
VGA, Digital, RS232
02 02 Wake Up From Sleep =
Never Sleep
