Quick Setup
Table 3-1 gives a quick overview of the display installation process. The sections following this one provide detailed
instructions.
Table 3-1. Installation Overview
Step Procedure For Details,
1 Mount the display(s) on a wall (optional) 27
2 Connect other external equipment to the display (optional):
Automation/control system (RS-232, Ethernet)
28
3 Connect signal sources to the display 30
4 Apply power to the display 32
5 Change the OSD language (optional) 33
6 Perform touch screen-specific installation and configuration tasks (VIVIDtouch):
Connect touch screen controller host computer to the display
33
7
Display calibration - adjust the following for each input:
Aspect ratio
Brightness
Contrast
Colour temperature and white balance
Color level
Tint
Input position
41
Installation Considerations
Proper installation of your display will ensure a satisfying viewing experience. Whether a display is installed temporarily
or permanently, the following should be taken into account to ensure the best performance of the display.
Ambient Light
In general, minimise or eliminate light sources directed at the screen. Contrast ratio in your images will be noticeably
reduced if light directly strikes the screen, such as when a shaft of light from a window or floodlight falls on the image.
Images may then appear washed out and less vibrant. Direct sunlight may affect touch operation.
Ambient Heat
Keep the ambient temperature constant and below 35°C (95°F). Keep the display away from heating and / or air
conditioning vents.
