65
7. Specifications
Table 7-1 lists the signal types supported by each input on the display.
VTF-6510 VTF-8410
PANEL
Diagonal Size (Inch)
65
84
Backlight
Edge LED
Aspect Ratio
16:9
Input Resolution
3840 x 2160 @ 60 Hz
Response Time
5.5 (typ) 5 (typ)
Brightness
450 (cd/m
2
)
350 (cd/m
2
)
Contrast Ratio
4000:1
1400:1
Viewing Angle
17(H) / 178º (V)
Supported Colours
1.07 G colours
1.06 Billion colours
Display Orientation
Lanscape compatible
TOUCH SYSTEM
Interface
Touch USB
Touch
High-resolution inGlasstouch; Up to 10 points
Glass
AG glass; 3 mm thickness
Supported Operating System
Windows 7 / 8 / 10
AUDIO
Built-in Speakers
4 / 2 x 10W
CONNECTIVITY
Connections
5 x HDMI / 1 x VGA / 1 x DisplayPort
Audio
Audio Out / PC Audio In / SPDIF
Control
2 x Touch USB / RS232 / Ethernet
MINI PC
CPU
Intel Atom Quad Core Processor
Memory
2GB DDR3
Storage
32GB (eMMC)
Ethernet
10/100 Mbps (RJ-45)
WiFi
802.11 b/g/n, 2.4GHz, 1T1R, Realtek RTL8723BS Module
Bluetooth
4.0
USB 2.0/3.0
x2 / x1 (Type A)
OS
Windows 10 Home Edition (x64)
PHYSICAL SPECIFICATIONS
Dimensions
1498.4 x 918.1 x 93.3 mm
1949.0 x 1187.8 x 95.2 mm
Weight
Net: 67 kg / Gross: 77 kg
Net: 111 kg / Gross: 118 kg
Wall Mount (VESA)
400 mm x 400 mm 600 mm x 600 mm
600 mm x 400 mm
IPC Mount
100 mm x 100 mm 100 mm x 100 mm
Fanless Design
Yes
Yes
OSD FUNCTIONS
OSD Languages
English, German, Dutch, French, Danish, Slovenian, Hungarian, Serbo-
Croatian
Source Auto Detect Function
Yes
