Command and Response Examples
Here are some examples of serial commands and their responses:
Table 6-1. Serial Command/ Response Examples
Serial Command List
Table 6-2 lists all supported commands.
Table 6-2. Serial Commands
Description Command sent to LCD Panel Response Received from LCD Panel
Turn LCD panel power off. 07 01 02 50 4F 57 00 08 07 01 00 50 4F 57 00 08
Turn LCD panel power on. 07 01 02 50 4F 57 01 08 07 01 00 50 4F 57 01 08
Request LCD panel power status. 07 01 01 50 4F 57 08 07 01 00 50 4F 57 XX 08
(XX = 0 when off or 1 when on)
Set the LCD panel contrast to 30
(1E hex).
07 01 02 43 4F 4E 1E 08 07 01 00 43 4F 4E 1E 08
Reset the LCD panel display settings. 07 01 02 41 4C 4C 00 08 07 01 00 41 4C 4C 00 08
Request LCD panel serial number. 07 01 01 53 45 52 08 07 01 00 53 45 52 S(0)…S(12) 08
S(0) …S(12) = the serial number in ASCII
Request LCD panel firmware version. 07 01 01 47 56 45 08 07 01 00 47 56 45 S(0)…S(5) 08
S(0) …S(5) = the firmware version in ASCII
Main Item Control Item CMD Type
Value
(DEC)
Reply
(DEC)
Content
CMD
(HEX)
Power Control and
Input Source
Power Control POW W/R
00
00
Off (soft power)
50 4F 57
01
01
On (soft power)
IPC Control IPC W/R
00
00
Off
49 50 43
01
01
On
Input Source MIN W/R
00
00
VGA
4D 49 4E
09
09
HDMI 1
10
10
HDMI 2
11
11
HDMI 3
12
12
HDMI 4
13
13
Displayport
14
14
IPC/OPS
17
17
HDMI 5 (Front Panel)
18 18
Media Player
(Win/Android)
Display Adjustment
Display
Adjustment
BRI
W/R
0~100
0~100
Back Light Brightness
42 52 49
BRL W/R 0~100 0~100
Digital Brightness
Level
42 52 4C
BLC W/R
00
00
Off (Back Light)
42 4C 43
01
01
On (Back Light)
CON
W/R
0~100
0~100
Contrast
43 4F 4E
HUE
W/R
0~100
0~100
Hue
48 55 45
